Overview

Operating Specifications

Rated Load Capacity9000 lb
Maximum Lift Height43 ft
Maximum Forward Reach31 ft
Capacity at Maximum Height7000 lb
Capacity at Maximum Reach1200 lb
Top Travel Speed19 mph
Frame Leveling10°
Turning Radius over Tires12 ft
Drawbar Pull (Loaded)21582 lbf

Engine

Engine ModelCat® C3.4B
Gross Power (Basic)111 hp
NoteMeets U.S. EPA Tier 4 Final emission standards.

Weights

Operating Weight25750 lb

Tires

Standard370/75-28 Duraforce MT
Optional13.00 × 24 Foam Duraforce

Hydraulic System

Pump TypeVariable displacement load sensing axial piston pump

Service Refill Capacities

Fuel Tank38 gal
Diesel Exhaust Fluid (DEF) Tank5.7 gal

Boom Performance

Boom Up9.9 Seconds
Boom Down8.5 Seconds
Tele In14.6 Seconds
Tele Out14.5 Seconds

Brakes

Service BrakesInboard wet disc brakes on front and rear axles
Parking BrakesWet disc, spring applied hydraulic release on front axle

Axles

TypesTrunnion mounted planetary 55 degree steer axles.
